Best Glass Drill Bits for Aquarium Overflow Holes
Drilling an overflow hole into a glass aquarium is one of those tasks that terrifies beginners — and for good reason. A wrong bit, too much pressure, or inadequate cooling can crack an expensive panel in seconds. Selecting the best glass drill bit for your aquarium project is the single most important step toward a clean, stress-free hole. At Gensou Aquascaping in Singapore, we have drilled hundreds of tanks over 20 years and learned exactly which bits deliver reliable results.
Diamond-Coated Hole Saws vs Spear-Point Bits
Diamond hole saws are the standard for aquarium work. They cut a circular plug from the glass, leaving a smooth bore ideal for bulkhead fittings. Sizes range from 20 mm to 50 mm to match common overflow pipe diameters. Spear-point carbide bits, by contrast, are designed for smaller pilot holes and are not suitable for bulkhead-sized openings. Stick with diamond hole saws for any hole wider than 15 mm.
Recommended Sizes for Common Setups
A 25 mm bit suits most nano and medium tanks running a 20 mm bulkhead fitting. Larger sumped systems — 120 cm tanks and above — benefit from a 32 mm or 40 mm hole to handle higher flow rates without restricting turnover. Always confirm the outer diameter of your chosen bulkhead before purchasing the bit; a 1 mm mismatch can mean the gasket will not seal properly.
Top Picks Available Locally
The Ista Diamond Core Drill Bit is widely stocked at aquarium shops along Serangoon North Avenue 1 and typically costs $12-18 depending on diameter. Its electroplated diamond coating handles standard 8 mm and 10 mm glass cleanly. For thicker 12 mm panels, a sintered diamond bit from industrial suppliers on Lazada (around $15-25) lasts longer because the diamond layer runs deeper into the metal matrix rather than sitting only on the surface.
How to Drill Safely
Lay the tank on a flat, padded surface with the panel to be drilled facing upward. Create a dam of plumber’s putty or modelling clay around the drill site and fill it with water — constant cooling prevents heat fractures. Run your drill at 600-800 rpm with light, steady pressure. Let the bit do the work; forcing it generates heat spikes that crack glass. The entire cut through 8 mm glass should take roughly 2-3 minutes.
Tempered Glass Warning
Never drill tempered glass. It will shatter instantly. Most aquarium base panels are tempered for structural reasons, while side panels are usually standard float glass. Check with your tank manufacturer before drilling. If you bought a second-hand tank with no documentation, a polarised light test using your phone screen and a pair of polarised sunglasses can reveal tempering patterns.
Extending Bit Lifespan
Rinse the bit in clean water after every use to flush out glass dust trapped between diamond particles. Store it in a padded case — bouncing around in a toolbox dulls the coating quickly. A quality diamond hole saw should last 15-20 holes in 8 mm glass before cutting speed noticeably drops. At that point, a replacement is cheap insurance against cracked panels.
When to Call a Professional
If your tank has curved panels, thick 15 mm glass, or if you simply feel uncomfortable with the process, hiring a professional is the sensible choice. Several aquarium service providers in Singapore offer on-site drilling for $30-60 per hole. The cost is trivial compared to replacing a cracked tank and dealing with water damage in an HDB flat.
